Description
USED - The Belcat DLY-603 Analog Delay is a compact, analog-style delay pedal designed to emulate the warm, vintage echo effects of classic delay units. The pedal is built around a hybrid circuit combining traditional analog components with a PT2399 delay processor, providing reliable analog-style tone in a durable enclosure. It delivers delay times ranging from approximately 130 to 350 milliseconds, making it suitable for slapback, rhythmic, and ambient delay effects.
Specs:
- Input Connector: 1/4’’ TS
- Input Impedance: 1MΩ
- Output Connector: 1/4’’ TS
- Output Impedance: 1KΩ less
- Power Connector: 2.5mm DC Jack
- Rate Control: 130ms - 350ms
- Power Supply: 9V (6F22) Battery or DC 9V ADAPTER
- Power Consumption: 18mA
- Connectors: Input Jack, Output Jack, DC input
- Controls: Time, Repeat, Level
- Bypass: True bypass
- Dimension: 4.33" X 2.44" X 1.97'
- Weight: 235g
