Description
Brand new pedal from Maxon!
Free Shipping to Continental U.S.
No power supply included.
Collar City Guitars is an authorized Maxon dealer and a Preferred Reverb Seller, buy with confidence!
--------------------------------
Originally released in 1974, the D&S Distortion & Sustainer creates the same silky, compressed fuzz that those vintage Muffs are famous for. Yet where Muffs have a tendency to “blanket” your original guitar tone, the D&S retains more of the original sound and feel of your instrument and amp.
By using hand-selected low-noise transistors, the D&S actually offers more gain than a vintage Black & Red, yet with a lower noise floor. That’s right – MORE distortion with LESS noise.
The smooth EQ sweep of the D&S Tone control covers a frequency range that is narrower yet more useful than the Pi’s – This tighter, more focused EQ provides superior note definition, even when playing chords.
The combination of these elements gives the D&S the ability to produce huge amounts of distortion with minimal alteration to your guitar’s tone.
One big wall of raw, grungy nastiness in a box – the D&S takes the sound of the greatest vintage Muff and turns it up to 11.
----------------------------------
TECH TALK:
The secret to the D&S’ smooth tone and natural response lies in two areas of its circuit. First, the Hi boost/Hi cut Tone control retains low end response while adding top-end clarity to notes. Next, high-grade, low noise Toshiba 2SC1815 transistors offer more intense distortion with minimal noise and signal degradation.
The D&S features buffered, JFET bypass switching with a low impedance output, allowing it to drive long cable lengths or other effect units without loss of signal.
Input Impedance: 500K Ohms
Input Jack: 1/4 inch standard phone jack
Output Impedance: 10K Ohms
Output Jack: 1/4 inch standard phone jack
Output: 1
Controls: Distortion, Tone, Balance
Switch: Normal/Effect
Noise (IHF-A): -110 dBu
Max Amplitude: 40 dBu
Power Voltage: DC9 V (Battery) / DC10 V (AC-adaptor)
Current Consumption: 6 mA (9V) / 7 mA (10 V)
Dimensions (main body): 61 mm (W) x 112 mm (D) x 35 mm (H)
Dimensions (whole): 70 mm (W) x 112 mm (D) x 55 mm (H)
Weight: 260 g
Non-skid pad: x 1
Warranty Card: x 1
User's Manual: x 1
Free Shipping to Continental U.S.
No power supply included.
Collar City Guitars is an authorized Maxon dealer and a Preferred Reverb Seller, buy with confidence!
--------------------------------
- Classic 70’s Transistor Distortion
- High Gain with long sustain & low noise
- Retains note definition, even with chords
- Sounds like a tighter, more refined Big Muff
- The EH Big Muff Pi defined the guitar tones of the 70’s and then re-defined them in the 90’s. Yet for all its legendary pedigree, the Pi of today is a far cry from the triangle knobs and ram’s heads that came before it.
Originally released in 1974, the D&S Distortion & Sustainer creates the same silky, compressed fuzz that those vintage Muffs are famous for. Yet where Muffs have a tendency to “blanket” your original guitar tone, the D&S retains more of the original sound and feel of your instrument and amp.
By using hand-selected low-noise transistors, the D&S actually offers more gain than a vintage Black & Red, yet with a lower noise floor. That’s right – MORE distortion with LESS noise.
The smooth EQ sweep of the D&S Tone control covers a frequency range that is narrower yet more useful than the Pi’s – This tighter, more focused EQ provides superior note definition, even when playing chords.
The combination of these elements gives the D&S the ability to produce huge amounts of distortion with minimal alteration to your guitar’s tone.
One big wall of raw, grungy nastiness in a box – the D&S takes the sound of the greatest vintage Muff and turns it up to 11.
----------------------------------
TECH TALK:
The secret to the D&S’ smooth tone and natural response lies in two areas of its circuit. First, the Hi boost/Hi cut Tone control retains low end response while adding top-end clarity to notes. Next, high-grade, low noise Toshiba 2SC1815 transistors offer more intense distortion with minimal noise and signal degradation.
The D&S features buffered, JFET bypass switching with a low impedance output, allowing it to drive long cable lengths or other effect units without loss of signal.
Input Impedance: 500K Ohms
Input Jack: 1/4 inch standard phone jack
Output Impedance: 10K Ohms
Output Jack: 1/4 inch standard phone jack
Output: 1
Controls: Distortion, Tone, Balance
Switch: Normal/Effect
Noise (IHF-A): -110 dBu
Max Amplitude: 40 dBu
Power Voltage: DC9 V (Battery) / DC10 V (AC-adaptor)
Current Consumption: 6 mA (9V) / 7 mA (10 V)
Dimensions (main body): 61 mm (W) x 112 mm (D) x 35 mm (H)
Dimensions (whole): 70 mm (W) x 112 mm (D) x 55 mm (H)
Weight: 260 g
Non-skid pad: x 1
Warranty Card: x 1
User's Manual: x 1
